ZAM Structure is currently the product with the largest increase in production and export volume at the Kinsend factory.

It is mainly used in large-scale ground projects, Waterproof carports, BIPV structures and other projects.

The use of ZAM material in photovoltaic mounting structures represents a very advanced choice, offering significant advantages, particularly in waterproofing (corrosion resistance).

ZAM material mounting structures outperform traditional hot-dip galvanized (GI) structures comprehensively in terms of corrosion resistance, long-term reliability, lifecycle cost, and environmental friendliness. They are currently the preferred choice for mid-to-high-end PV projects, especially in coastal, industrial, or humid areas with high corrosion resistance requirements.

Revolutionary Coating Structure and Composition:

ZAM is a general term for Zinc-Aluminum-Magnesium coatings. In addition to zinc (Zn), its composition includes precisely proportioned aluminum (Al) and magnesium (Mg) (e.g., ZnAl6Mg3), and sometimes silicon (Si).

This alloy coating forms a dual mechanism on the steel surface: "Sacrificial Anode Protection" + "Dense Barrier Protection."

Aluminum (Al): Forms a dense alumina film on the coating surface, acting as the first physical barrier, significantly slowing the penetration of corrosive media.

Magnesium (Mg): Greatly enhances the coating's "self-healing" capability. When the coating is scratched or cut, magnesium promotes the faster and denser formation of corrosion products over the cut edge, creating a protective layer that prevents red rust formation. This is its most outstanding feature.

Exceptional Corrosion Life Data:

With the same coating thickness, ZAM's corrosion resistance is typically 3-10 times or more that of ordinary hot-dip galvanized (GI) steel.

In neutral salt spray tests, ordinary galvanized steel (100g/㎡) may show red rust after about 500 hours, while ZAM coating of the same thickness can last 2000-3000 hours or even longer.

This means that in harsh environments (e.g., C4 highly corrosive industrial areas, C5 coastal areas), ZAM structures can guarantee a design service life of 25 years or more, better matching the lifespan of PV modules.
