Common fixed types of ground installation Basic:
1, hammer into the pile It is convenient and quick to measure the distance at the installation site and directly drive the column into the ground with a pile driver. Before installation, geological soil testing should be done to determine the appropriate hammering depth. The following profiles are suitable for hammering piles, which are selected according to the actual situation:
Advantages: Fast speed and strong adaptability; High cost performance; Not limited by seasonal temperature; It is convenient to pull out the ground pile without affecting the reuse of the installation site.
2. Spiral ground pile When the installation site is too hard, or there are too many broken stones, it is inconvenient to hammer the upright column directly into the ground, and the spiral pile can be selected. Drive the screw-in steel pipe into the ground, and then fix the column on it. Advantages: Strong adaptability and flexible combination; Not limited by seasonal temperature; It is convenient to pull out the ground pile without affecting the reuse of the installation site.
3. Precast cement foundation If the installation site is not suitable for plug-in piles, cement foundation can be selected, and the bracket is placed on the cement foundation and fixed with bolts. Advantages: Good strength and high precision; Strong adaptability to the ground.
4. Direct cement pouring Another form of cement foundation is to directly pour the bracket and cement together. In this way. Compared with the above one, the time of bolting and fixing is saved, but the positioning accuracy of the support column is required to be higher when pouring. Advantages: Good strength and high precision; Strong adaptability to the ground. Common ground support forms
1. Plug-in ground fixing form Plug-in ground fixing bracket Features: (1) the main body of the bracket adopts structural steel, and the surface is hot-dip galvanized, with a service life of more than 20 years; ② All parts have good coordination and convenient installation; ③ Convenient maintenance; ④ Strong adaptability to the ground.
2. Ground truss type fixing form Ground truss type fixing bracket Features: (1) the use of spiral pile, easy to operate (can also use other ground fixed way); ② Adapting to many different types of geology; ③ aluminum guide rail with strengthened design is adopted for the crossbeam; ④ Slots for installing components are designed on the aluminum guide rail, which makes the installation and fixation of components simple and convenient.
3, the ground single column fixed form solar Ground single-column fixing bracket Features: (1) The supporting aluminum rail specially designed for installing crystalline silicon solar components is adopted, which makes it very convenient to install and fix the solar module and reduces the installation time; ② Bearing parts such as columns and beams have been strengthened to meet the requirements of large working load; ③ wiring grooves are integrated on the beam, which makes the construction more convenient.
4. Tracking bracket form Uniaxial tracking A tracking system that rotates around a one-dimensional axis so that the plane of the photovoltaic module is vertically incident by sunlight as much as possible. Flat uniaxial tracking system Inclined uniaxial tracking system
Kinsend looks forward to receiving more information about your case and providing reasonable pv design solutions.
